BMS NMC 17S 50A JBD (ZP20S007)
Regular price
Rs. 1,190.00 INR
Regular price
Sale price
Rs. 1,190.00 INR
✓ Taxes Included
✓ Free Returns
The JBD ZP20S007 V1.5 is a high-quality Battery Management System (BMS) engineered for 17S (62.9V nominal) Li-ion/NMC battery packs. With a 50A continuous current rating, this BMS provides intelligent protection, passive balancing, and a compact design that makes it ideal for medium-to-high power battery energy storage and mobility applications.
Technical Specifications
| Feature | Detail |
|---|---|
| Battery Chemistry | Li-ion / NMC (3.7V nominal per cell) |
| Configuration | 17S (62.9V nominal / 71.4V max) |
| Continuous Current | 50A (Charge/Discharge) |
| Port Type | Common Port (Shared for charge/discharge) |
| Balancing Type | Passive Balancing |
| Balancing Current | Approx. 60mA |
| Overcharge Protection | ~4.25V/cell |
| Overdischarge Cutoff | ~2.8V/cell |
| Static Power Draw | ≤60μA |
| Internal Resistance | ≤15mΩ |
| Operating Temp | -20°C to +75°C |
