BMS NMC 16S 50A SMART CAN DALY

The BMS NMC 16S 50A SMART CAN DALY is a high-performance battery management system designed for 60V (16S) Lithium-ion (NMC) battery packs. With intelligent communication protocols such as CAN and UART (RS485), this BMS is ideal for applications in electric vehicles, solar energy storage, robotics, and other high-efficiency lithium battery setups. Built by DALY Electronics, this system is renowned for its robust protection, thermal monitoring, and stable current handling.

Technical Specifications

• Battery Configuration: Smart BMS Li-ion 16S 60V 50A Common port with Balance
• Continuous Discharge Current: 50A
• Balance detect Voltage 3.8
• Charge Current: 25A
• Charge Voltage: 67.2V
• Short Circuit Protection: Yes, with auto recovery
• Temperature Protection: Over-temperature and under-temperature protection
• Features: Overcurrent, overcharge, over-discharge, and temperature protection

Key Features

• CAN Bus & UART Communication: Allows integration with EV controllers, display systems, and chargers, enabling real-time data exchange, SOC display, and diagnostic feedback.
• Multiple Safety Layers: Provides over-voltage, under-voltage, over-current, short circuit, and temperature protections, thereby ensuring long battery life and safety.
• Real-Time Monitoring: With advanced sensor support and firmware, monitor charging/discharging performance, cell voltage variations, and temperature parameters effectively.
• Efficient Current Handling: Capable of delivering and managing up to 50A discharge, making it suitable for mid-power applications such as e-scooters, solar banks, and portable devices.
• Smart Thermal Control: Equipped with NTC sensors to detect high or low-temperature conditions and initiate automatic cutoffs to prevent damage.
• User-Friendly Design: Plug-and-play wiring layout with clear P- and B- terminals for seamless installation in new or retrofit battery systems.

Applications

• Electric Scooters & Motorbikes (60V Li-ion)
• Solar ESS (Energy Storage Systems)
• Portable Lithium Power Stations
• Medical and Industrial Robotics
• UPS Backup Systems for Telecom & IT
• Lithium-ion DIY Pack Protection
