71V 6A Lithium EV Charger

Key Features

• Optimized for 60V (17S) Lithium-Ion Batteries: Specifically engineered to charge 60V (17-series cell) lithium-ion battery packs efficiently, ensuring compatibility and reliable performance.

• 6A Charging Current: Provides a 6-amp charging current, balancing rapid charging with battery health maintenance.

• Three-Stage Intelligent Charging Mode: Incorporates a three-stage charging process—Constant Current (CC), Constant Voltage (CV), and Trickle Charge—to ensure batteries are fully charged without overcharging.

• Smart Charging Technology: Features intelligent microprocessor-controlled charging protocols to prevent overcharging, overheating, and short circuits, safeguarding both the charger and the battery.

• LED Charging Indicators: Equipped with clear LED indicators to display charging status, including power on, charging in progress, and fully charged states.

• Durable Aluminum Alloy Shell: Constructed with a robust aluminum alloy casing, the charger is designed to withstand regular use and dissipate heat effectively.

• Comprehensive Safety Features: Includes protections against overvoltage, overcurrent, short circuits, and overheating, ensuring safe operation.

• Energy Efficient: Designed to consume minimal energy while delivering maximum charging efficiency, contributing to lower electricity costs.

Product Specifications

• Model: AL 71.4V 6A Electric Vehicle Battery Charger

• Input Voltage: AC 96–265V, 50/60Hz

• Output Voltage: 71.4V DC

• Charging Current: 6A

• Battery Compatibility: 60V (17-series cell) Lithium-Ion Battery Packs

• Charging Status Indicators: LED Display (Power On, Charging, Fully Charged)

• Safety Features: Overvoltage Protection, Overcurrent Protection, Short Circuit Protection, Overheating Protection

• Dimensions: Approximately 189 x 99 x 54 mm

• Weight: Approximately 1.0 kg

• Output Connector Type: Various options available, including ICE13, GX16-3PIN, XT60, XLR-3PIN

• Cooling Mechanism: Fan cooling for efficient heat dissipation
